BT function
  LED display
  Supports USB and SD/MMC
  Built-in FM
  Fully functional remote control
  Stylish design
  Total output power (RMS) 65W
  Subwoofer 35W
  Satellite 6W x 5
  Frequency response 40Hz - 20KHz
  S/N ratio ≥75dB
  Separation ≥50dB
  Subwoofer drive size 10.1cm (4)
  Satellite drive size 6.8cm (2.7) x 5
  Input 3.5mm
  Subwoofer  Dimension 140 x 275 x 257 mm (W x D x H)
  Satellite Dimension
  Center  90 x 80 x 130 mm (W x D x H)
  Front  90 x 80 x 130 mm (W x D x H)
  Rear 90 x 80 x 130 mm (W x D x H)
  Box dimension 337 x 305 x 283 mm (W x D x H)
  Net. Weight 4.4 kg
  Wall mount Yes (satellites)
  BT specification
  BT version 2.1
  Frequency 2.402GHz-2.480GHz
  Max. transmit power 2.3dB
  Power sensitivity 80dB/mv
  Range 10 meters
  Data rates 1.8 Mbps-2.1Mbps
  BT pairing name ZEBRONICS
  Accessories
  User manual
  Remote
  RCA to Stereo Converter
  RCA-RCA
  RCA to open
  Wall mount clamp (5 Nos)
  Screws
