Zeb 8PPM2UM

Sale price₹ 3,999.00

Inclusive of all taxes


Product Type: Unmanaged POE

Specifications


Connector Type 8 Port 10/100M PoE + 2 Port 10/100M Ethernet Uplink

Network Media 10BASE-T: Cat 3,4,5 UTP(≤100 meter)
10BASE-T: Cat 6 UTP(≤250 meter)
100BASE-TX: Cat5 or more UTP (≤100 meter)

Performance Specification Bandwidth: 2Gbps (non-blocking)
MAC: 1K
Packet Buffer Memory: 448K
Packet Forwarding Rate: 0.1488Mpps/port\

Forwarding Mode
Store-And-Forward

Network Protocols
IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control;
IEEE 802.1af/at DTE Power via MDI; IEEE 802.3af/at

LED Display System: power supply; Every Port: connecting, PoE working status

Power Supply Power input : AC110-260V 50/60Hz;
Output : 52V2.88A,
Power Budget : 150W

PoE Ports PoE PortsPort 1-8 support POE

PoE Port Power 15.4W/30W for each POE port

PoE Standard IEEE 802.3af/at

Led indicator


PWR Power supply indicator(Red)    Lighting:Powered
Un-Light:No Power

SW   Vlan: Lighting
Extend: Slow flash

1-10
RJ-45 ACT indicator(Green)
Lighting:Connecting
Flashing:Data Transmit
Un-Light:Disconnect

Working Environment

Operating Temperature:
-20°C ~ 55°C;

Storage Temperature
-40°C ~ 85°C;

Operating Humidity
10% ~ 95%, non-condensing

Transmission Distance Data transmission distance: 100m, 250m( when on 10M data rate with Cat6.)

Dimension(L×W×H)
222mm*163mm*40mm

Port Surge Protection
4KV

AI function> POE Watchdog

MTBF 100,000 hours

Country of Origin China

Package Contents

Ethernet Switch 1 unit

User Guide 1 unit

Warranty Card 1 unit

Power Cord 1unit
