Supported CPU | Intel i7/i5/i3 series processors | |
Chipset | Intel B75 chipset | |
Memory supported | 2 DDR3 Dual channel RAM slots memory, up to 8GB, supports DDR3 1066/1333/ 1600MHz memory |
|
BIOS | EFII Bios | |
I/O interface | 1 x HDMI Port, 1 x VGA Port, 4 x USB 2.0 Port, 2 x USB 3.0 Port 1 x RJ45 Port, 1 x 3-in-1 Audio | |
Onboard interface | 1 x 24 pin ATX power connector, 1 x 4 Pin ATX 12V power connector, 2 x SATA 2.0 Gb/s connectors, 2x SATA 3.0 Gb/s connectors, 1 x USB 2.0 Header, 1 x USB 3.0 Header, 1 x Front audio connector, 1 x Front panel connector, 1 x Speaker connector, 2 x Fan connectors |
|
Integrated LAN | 10/100 Mbps LAN | |
Expansion slot | 1 x PCI Express x16 slot, 1 x PCI Express x1 slot | |
Form factor | Micro-ATX | |
Country of Origin | China | |
|
||
ZEB-B75 Motherboard | ||
SATA cable | ||
I/O backboard | ||
Driver disc | ||
User manual |
This is a really good MOBO if you are building test benches with 2nd or 3rd Gen CPUs. It has all the functionalities of a modern MOBO, 4 SATA slots, which are very much required for development and testing purposes. The only thing that misses, out here is the lack of WIFI support, but most people usually either get a wifi CARD, corresponding to theeir routers or use LAN. Great stuff, and a great step towards AtmaNirbhar BHARAT.
