Zeb C4PCAT6CCA-305M-PLUS
Inclusive of all taxes
Product Type: CAT 6 Cables
Zeb C4PCAT6CCA-305M-PLUS
Sale price₹ 6,299.00
Specifications
Model Name |
ZEB-C4PCAT6CCA-305M-PLUS | |
No. of wires |
4 pairs | |
Cable length |
305 meter | |
Conductor material |
24 AWG Solid Bare CCA | |
Construction diameter |
0.508 mm | |
Insulation material |
PE | |
Insulation thickness |
0.2mm | |
Insulation diameter |
0.90mm | |
Jacket material |
PVC | |
Jacket thickness |
0.65mm | |
Jacket diameter |
6.1mm | |
Jacket color |
Gray | |
Separator |
PE Central cross separator | |
Conductor resistance |
< 93.8Ω/km at 20°C | |
Weight |
9.94Kg | |
Country of Origin |
India | |
Mechanical Properties | ||
Operation Temperature |
-10°C to +60°C | |
Storage Temperature |
0°C to +50°C | |
Bending Radius |
<25.4 mm at -20°C to ±1°C | |
Pulling Force | 8 Kgs |
