ZEB-C4PCAT6CU-305M-Plus

Sale price₹ 9,899

Product Type: CAT 6 Cables

Specifications


Model Name
ZEB-C4PCAT6CU-305M-PLUS

No. of wires
4 pairs

Cable length
305 meter

Conductor material
25 AWG Solid Bare Copper

Construction diameter
0.45mm

Insulation material
PE

Insulation thickness
0.2mm

Insulation diameter
0.970mm

Jacket material
PVC

Jacket thickness
0.65mm

Jacket diameter
6.1mm

Jacket color
Gray

Separator
PE Central cross separator

Conductor resistance
< 93.8Ω/km at 20°C

Weight
14.08Kg

Country of Origin
India

Mechanical Properties

Operation Temperature
-15°C to +60°C

Storage Temperature
0°C to +50°C

Bending Radius
<25.4 mm at -20°C to ±1°C

Pulling Force 10.5 Kgs
