| Supported CPU | Intel Core 2 Quad/ Core 2 Duo/ Pentium Series/ Celeron Series Processor North Bridge - Intel G41 | |
| Chipset | South Bridge - Intel ICH7 Chipset | |
| Memory supported | 2 DDR3 dual-channel RAM slots, Memory up to 8GB ( Double Bank RAM) Supports DDR3 \ 800/1066MHz memory, 2 x DIMM Slots |
|
| BIOS | AMI BIOS | |
| I/O Interface | 1 x PS/2 keyboard port, 1 x PS/2 mouse port, 1 xVGA Port, 1 xCOM port, \ 4 x USB 2.0 ports, RJ45 LAN port, 1 x 3-in-1 audio jacks |
|
| Onboard interface | 1 x Front panel connector,1 x Front audio connector, 2 x USB 2.0 Connector, \ 4 x SATA Ports, 1 x 1 IDE slot,1 x 4 pin CPU fan connector, \ 1 x 24-pin ATX power connector, 1 x SYS Fan Connector, \ 1 x 4-pin ATX 12V power connector, 1 x clear CMOS header |
|
| Integrated LAN | Supports RTL8105E 10/100 Mbps Ethernet LAN | |
| Expansion slot | 1 PCI Express x16 slot, 1 PCI Slot | |
| Form factor | Mirco-ATX | |
| Package contents | ||
| G41-D3 Motherboard | ||
| I/O Backboard | ||
| SATA Cable | ||
| IDE Cable | ||
| Driver disc | ||
| User manual | ||
