  • ZEB H81GL M2 - LGA 1150 SOCKET
ZEB H81GL M2 - LGA 1150 SOCKET
ZEB H81GL M2 - LGA 1150 SOCKET

ZEB H81GL M2 - LGA 1150 SOCKET

New
Sale price₹ 5,599.00

Inclusive of all taxes

  • Supports DDR3 1066/1333/1600 MHz
  • LGA 1150
  • 5.1 Audio
  • 3 x SATA. PCle
Product Type: Motherboards

Specifications


 Supported CPU Socket 1150 / Intel Pentium / Celeron / i3 / i5
/ i7 (4th & 5th Generation) Series Processors

Chipset
 Intel H81 Chipset

Memory support 2 x DDR3 DIMM memory slots,
Memory up to 16GB
Supports DDR3 1066/1333/1600 MHz memory

BIOS AMI BIOS

I/O Interface 1 x HD, 1 x VGA, 6 x USB2.0,
1 x RJ45, 1x 3-in-1 Audio Jacks

Onboard Interface

1 x 24 pin ATX Power Connector,
1 x 8 Pin ATX 12V Power Connector,
1 x USB 2.0 Header, 1 x USB 3.0 Header,
1 x Front Audio Connector, 1 x Front Panel Connector,
1 x Speaker Connector, 1 x 3 pin CPU fan connector,
1 x SYS Fan Connector, 1 x SATA 2.0 Ports,
2 x SATA3.0 Ports ,1 x clear CMOS Connector,
1x M.2 Slot (NVMe / SATA Mode),
1 x Debug card header


Integrated Sound With 5.1-Channel HD Audio

Integrated LAN Supports RT8111F/E 10/100/1000 Mbps Ethernet LAN

Expansion Slot 1 x PCI Express 2.0 x16 size slot

Country of Origin PRC

Package Contents

Motherboard 1 U

SATA Cable
 1 U

I/O Backplate
 1 U

Driver Disc
 1 U

User Manual
 1 U
