Zeb-U775

Rs. 3,399.00
Zeb-U775 is a line-interactive UPS that is Micro-controller based with overload protection, generator compatible, Boost & Buck AVR, sleep mode charging, wide input range and more.
DESCRIPTION

Features


Line interactive UPS

Auto restart while AC is recovering

Double boost

Automatic voltage regulation (AVR)

Wide input range

Microcontroller based

Generator compatible

Specifications



Capacity


(VA/W) 650VA/360W


Input


Nominal voltage 220-240 VAC

Voltage range 140-300 VAC ± 7 Vac

Frequency 40-70 Hz ± 1 Hz

Plug type 3 Pin plug


Output


Voltage range (AC mode) 195-262Vac ±7Vac

Voltage range (Batt. mode 230VAC ± 10 %

Frequency range (Batt. mode) 50/60Hz ±1%

Transfer time 4ms TYP

Waveform Simulated sine wave

No. of output sockets 3

Protections Overload, Short circuit, Over discharge & Over charge


Battery


Battery type 12V 7Ah x 1 no

Charging current 12V 7Ah x 1 no

Recharge time 4 hours to charge 90%


Indicators



No. of LEDs 1 LED

AC mode Green lighting

Battery mode Green flashing


Alarm


Battery mode Beeping every 30 seconds

Low battery Beeping every 2 seconds

Overload Beeping every 0.5 seconds

Fault Continuous beeping


Physical details

Product dimension (W x D x H) 87 x 277 x 165 mm

Net. weight 4kg

Package dimension (WxDxH 319 x 126 x 232 mm


Environmental factors

Operational temperature 0-40⁰C

Noise level < 40dB




Country of Origin
China
